Canoe Douglas Fir Plywood sheathing is a high-strength, unsanded structural panel engineered specifically for the demanding needs of the construction industry. As the original engineered wood product, our plywood panels provide a level of reliability and structural integrity that modern substitutes struggle to match.
Each panel is crafted by laminating layers of high-quality wood veneer with phenolic resin adhesive. Through a process of intense heat and pressure, these layers are cross-laminated—alternating grain directions—to create a panel with exceptional dimensional stability and uniform strength. Once the phenolic resin cures, it becomes a permanent bond that is unaffected by moisture or heat.
Produced to meet CSA 0121 (DFP) and CSA 0151 (CSP) for Canadian Structural Plywood, and US Standard PS-1 for Structural Plywood.
Canoe Douglas Fir Plywood is rated for load-bearing use in both single-family and multi-family residential projects, as well as commercial builds.
Canoe DFP Sheathing is available in standard 4′ x 8′ sheets.
| Nominal Thickness (Imperial) | Metric (mm) | Plies | Pieces Per Unit | Approx. Weight (lbs/sheet) |
| 3/8” | 9.5mm | 3 | 80 | 33.6 |
| 1/2” | 12.5mm | 4 | 60 | 44.8 |
| 5/8” | 15.5mm | 5 | 5 | 56.0 |
| 3/4” | 18.5mm | 6 | 40 | 64.4 |
| 1” | 25.5mm | 8 | 30 | 89.6 |
| 1-1/8” | 28.5mm | 9 | 26 | 100.8 |
